种类与简单/Brief Introduction：

全定时液压泵式膏体酱装灌机.我新公司适合贸易市场业务需求的开发的新护肤品。终端服务器利用SUS304不锈钢装饰管吗液压泵式的计量泵进行装灌，且集定时上盖、定时旋盖、汽车电器电子商务为合一，实惠有用，占房屋地绿地面积绿地面积小，普遍利用于生物制药、面制品、农药杀虫剂、矿业、化淡妆品等该行业的液滴打包，贴合GMP实验室管理标准符合要求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

优势特点/characteristic：

◆分为齿轮泵式检定泵执行程序装灌，适用于各种各样黏黏度液，精度等级高；泵的构成分为快接式拆御设备，利于冲洗、灭菌。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆注塞泵式计量检测泵火塞环所选原材料原料依照服务业及夜体材料的各种不同应用硅再生胶，四氟氯乙烯或其他所选原材料原料，比较特殊场景应用瓷质所选原材料原料。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC设定体统，变頻调压，半自动方面高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不装灌，会自动计数法作用。Lack of bottle filling, automatic counting function◆装量优化便于，可是一次优化另一个计量检测检测泵的充填量，也可面对各计量检测检测泵去微幅优化；进行简易，优化很快。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆罐装针头下设防渗漏装置设备，充填时入侵瓶底罐装，慢慢地攀升，处理利用气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆裸机可适用人群各不相同规模的塑料瓶，調整非常简单，可在瞬周期内完工。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆服务器按GMP需要开发。The machine designed according to the requirements of GMP

枝术技术指标/technic parameter：

符合罐子技术参数Size of bottles	20-1000ml（通过条件定制）20-1000 - ml (according to your need）
采用玻璃瓶直径约Apply the bottle diameter	¢20-¢150mm
可用于盖子尺寸Apply the lid specifications	¢20-¢70mm
生产的作用 production capacity	四头装罐：1000-2500瓶/小时内 Four filling head: 1000-2500 bottles per hour 八头罐装：2500-4000瓶/半小时 Eight head filling: 2500-4000 bottles per hour 12头灌装线：4000-6000瓶/个钟头 12 head filling: 4000-6000 bottles per hour
装量误差率The load error	±1%
旋盖达标率Screw cover percent of pass	≥99%
电源模块power supply	380V，50HZ
功效power	3.0KW
源gas sources	0.4-0.75MPA
强度操作speed control	调频变速variable speed
