妙用与简单/Brief Introduction：

机器是充当服食药液玻璃纸纸瓶的新新型产品，充分消除了一直以来服食药液玻璃纸纸瓶的无良功能。该种灌封机使用的金属瓶，才能不需求洗瓶机、真空干燥机，更不需求清洁，需要一直灌封。这个机器全系统自动理瓶、进瓶、装灌，装灌量平衡，无漏滴，无瓶不装灌。上盖、塑封率能达到100%。此机枝术为先进，体积大小小、执行平衡、背景噪声低，实际操作检修、除污利于等作用，彻底满足GMP基准。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本款型有低速档和公路不同产量比供您选择。Note: this model has two kinds of low speed and high-speed production for your choice.

特质 Characteristic

◆滤油机可用来于各种类型易折瓶口服药液计算灌装设备和封好。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆其他电气器件均用着名店牌。All electrical components adopt famous brand◆该机运作形象化省事，无瓶不分装，计量校准*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折塑料制品瓶灌封机的关键框架与操作过程Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型内服液易折金属瓶灌封机其主要理瓶器、理盖器、主链传动程序、微信同步带腐蚀痕迹送单瓶置、瓶子检漏装备、灌装设备组织 、删去装备、热溶封组织 、手动设备手腕夹瓶组织 、步进驱动器电机的腐蚀痕迹上瓶组织 与出瓶组织 等组建。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆工具用的口服药液易折可塑料饮料瓶、盖一定洁净度区制造的，需要药粉材许证书证，所以咧瓶身与底盖经引入和"去外包服务"后可会直接流入灌封间。依据理盖器、理瓶器的自功定位分配归置，移除倒置底盖及瓶身底口朝下的瓶，使定位分配后的包材喂料有规范地流入推送轮轨中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定项后口服方式液易折朔料瓶在气力输送机轨道列车总排名Directional oral liquid after folding plastic bottles in conveying rail out easily

技木指标technical parameters：

型号model	NLGFY-40	NLGFY-80
装量超范围The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
封膜率Hot sealing intensity	》99%
装量误差度The load error	《1.5%
脏污率damage rate	《1.0%
输出power	2KW	3KW
主机电源Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
总重量 Weight	700Kg	800Kg
